8.2. Description of the maintenance operations
8.2.1. Clean the air lter
Open the maintenance cover.
Check the intake area for the combustion air.
Removelargerobjectsthatmayclogtheltersuchas
leaves or rocks.
Unscrewtheairltercover(1).
Removetheknurlednutontheairlter.
Removetheairlterinsert(2).
ATTENTION! Danger of material damage from dirt particles.
Keep dirt or foreign objects from entering the intake
opening.
Blowouttheairlterinsertfrominsidetooutsidewith
compressed air.
Checkand,ifnecessary,replacetheairltercartridge.See
also Hatz instructions.
Tightentheairltercartridgeusingtheknurlednut
Screwontheairltercover.
Close the maintenance cover.
8.2.2. Check V-belt
Shut down the machine.
Remove the V-belt guard (1).
Check the V-belt (2) for cracks and wear.
Replace the V-belt if it shows signs of extensive wear or
other damage.
Fit the V-belt guard.
1
2
1
2
