B-5
Install igniter
Note - The igniter wires are already attached to the
Gas Catcher Ignition Chamber and the igniter. This
was done to factory test the ignition system.
The igniter lock nut is on the igniter.
1) Loosen the igniter lock nut.
2) Insert the top of the igniter up through the large
part of the keyhole in the frame brace. Slide the
igniter into the small part of the keyhole.
3) Tighten the igniter lock nut back onto the igniter.
Note - If the igniter works loose, carefully tighten the
igniter lock nut with an adjustable wrench or pliers.
(1)
(2)
(3)
The wire holder (1) is to keep ignition wires from
interfering with the swing-up table’s bracket. If the wire
holder becomes loose, reinstall or replace it
immediately.
