10 CF 3 L
Technical data
CF 3
Weight
Operating weight CECE in kg 113
Dimensions
Overall length (in mm) 1160
Overall width (in mm) 500
Height with folded manual guidance rod (in mm) 640
Base plate length (in mm) 400
Pressure surface (in mm) 400x500
Drive
Engine manufacturer Lombardini
Type 15LD225
Performance at operating speed in accordance with ISO 3046-1 (kW) 3,5
Combustion process 4-stroke diesel
Operating speed (1/min) 3000
Drive speed forward (ground-dependent in m/min) 24
Incline capacity (ground-dependent in %) 30
Area capacity (in m²/h) 720
Vibratory
system Single shaft vibrator
Drive concept Mechanical
Frequency (in Hz) 95
Centrifugal force (in kN) 20
CF 3
Noise emissions in accordance with 2000/14/EC
Sound pressure level L
PA
ascertained in accordance with EN 500, in dB (A)
99
Sound pressure level L
WA
ascertained in accordance with EN ISO 3744 and EN 500, in dB
(A)
108
Vibration values
Root-mean-square acceleration value for hand-arm vibration
ascertained in accordance with EN 500 in m/s²
4,8
In accordance with directive 2006/42/EC,
complying with the vibration values is the owner‘s
responsibility.
