Weber CF 3 - Page 13

CF 3 L 13
Mounting the Poly pad
Hook in the Poly pad (1) at the rear.
Ensure that the Poly pad rests under the base plate.
Open and remove the gas cap (1), check the level, if
necessary top off to the lower edge of the ller neck with
clean fuel in accordance with the specication.
The correct oil level is between the min. and max. marks.
Check the engine oil level
Pull the oil dipstick (1) out of the crankcase.
Check the fuel level
Insert the oil dip stick in the oil ller neck, however do
not screw it in.
1
1
Fasten with holder, screws, spring-lock washers and nuts
(1) on the base plate front.
1
For work at the fuel system, have a suitable re-extin-
guishing agent at the ready.
Fire, naked light, and smoking is forbidden!
1
Min:Max
