Weber FT 600 - Page 40

40
12. Slide the burner assembly from each Heat Zone.
The left and right burners are connected by the
Crossover tube. Figure 20(a).
Figure 20
Crossover tube
Pull out of here
10. Unlatch the Spider Stopper Guards and remove.
Figure 18.
Figure 18
Manifold
11. Pull the manifold out of the burners. Figure 19.
Figure 19
