DIGITAL OUT Provides control signal for external illuminator which is
synchronized with image process.
- DURATION(0~20) : Set the one cycle duration of TTL
signal output (unit : msec)
- POLARITY : Set the output level of TTL signal.
(0 : 0V , 1 : 3.3V)
* Output cycle is decided by 30Hz/25Hz.
BOARDRATE
(9600, 57600)
Set RS485 communication speed.
RESET Make all configurations as factory default.
EXIT SAVE&EXIT Save configuration and exit menu.
EXIT Without saving configuration, exit menu.
If there is no further action in menu, after 1 minute,
OSD menu will exit without saving changes.
Product Specification
Model C1080PBM
Video
Sensor Type 1/3”, 2.1Megapixel CMOS
Total Pixels 1920(H) x 1080(V) = 2.1M pixels
Scanning System Progressive Scan
Min
Illumination
B/W 0.0005Lux@50IRE, F1.2, 3100K, DSS(OFF), AGC(10)
Color 0.2Lux@50IRE, F1.2, 3100K, DSS(OFF), AGC(10)
Lens
Mount CS/ C(Ring Adaptor)
Type DC Auto Iris, Manual
Video
Output
Output 1(BNC 1.0 Vp-p, 75Ω)
Resolution 1080p 30fps / 25fps, 720p 25fps / 30fps
HD-SDI SMPTE 292M compatible
Distance approx. 180m of RG6, 140m of RG59
Video
Control
Control Method DVR, CMS(Control Center),Remocon(5Push Bottons)
Filter True Day & Night
AGC 1 ~ 10 steps
Mirror Horizontal / Vertical
WDR OFF, 0 ~ 4 setup
BLC OFF, LOW, MIDDLE, HIGH
ACE OFF, ON
DNR OFF, LOW, MIDDLE, HIGH
DSS AUTO, OFF, x2 ~ x10
White Balance AUTO, PRESET, MANUAL
Defog OFF, AUTO, MANUAL
