3
ENGLISH
Attach both wall mounts to the pole
feet located on the pole and fully
extend the pole.
Insert the attached pin into the hole on
the lower bracket to secure wall mount.
Adjust the pole foot bracket so there is
at least 4 feet (1.25 meters) of
separation between the top and
bottom pole feet and wall mounts.
WARNING: Check for and avoid any
powerlines or overhead obstructions.
When the pole is mounted, do not
move the RV. Pole should be taken
down prior to winds over 35 mph (56
kph) and lightning occurances.
(STEP 2 cont.)
upper Pole
Foot
Wall Mount
Twist each
upper section
counter-clockwise,
extend, and then
turn clockwise to
lock into place.
NOTE: Use an app
like Opensignal to
point the outside
antenna toward the
nearest cell phone
tower.
Pole Foot
Pole Foot
Pin
4 ft. (1.25 m)
Wall Mount
lower Pole
Foot
Wall
Mount
t
i
g
h
t
e
n
/
l
o
o
s
e
n
To Next Page
