weBoost Drive 4G-M Quick Install Guide

Need help? www.weboost.com
Customer Support 866-294-1660
Mon.- Fri. Hours: 7 am to 6 pm MST
9
ENGLISH
Signal Booster Specifications
Drive 4G-M
Model Number 470008
Connectors SMA
Antenna Impedance 50 Ohms
Frequency 704-746 MHz, 746-787 MHz, 824-894 MHz, 1850-1995 MHz, 1710-1755/2110-2155 MHz
Passband Gain (typical)
700 MHz Band 12/17
47.6
700 MHz Band 13
46.8
800 MHz
47.6
1700/2100 MHz
43.6
1900 MHz
42.5
20 dB Bandwidth (MHz)
700 MHz Band 12/17 700 MHz Band13 800 MHz 1700/2100 MHz 1900 MHz
Typical
Maximum
26.8
30.8
27.5
30.8
39.3
40.6
76.1
80.4
79.4
80.0
Power output for single cell
phone (Uplink) dBm
700 MHz Band 12/17 700 MHz Band13 800 MHz 1700 MHz 1900 MHz
25.7 24.4 25.1 23.8 25.2
Power output for single cell
phone (Downlink) dBm
700 MHz Band 12/17 700 MHz Band13 800 MHz 2100 MHz 1900 MHz
-4.3 -4.1 -1.2 5.6 4.0
Power output for multiple
received channels
(Uplink) dBm
No. Tones
Maximum Power
700 MHz Band12/17 700 MHz Band13 800 MHz 1700 MHz 1900 MHz
2 23.0 20.0 20.7 20.5 21.2
3 19.4 16.5 17.2 16.9 17.7
4 16.9 14.0 14.7 14.4 15.2
5 15.0 12.1 12.7 12.5 13.2
6 13.4 10.5 11.2 10.9 11.7
Power output for multiple
received channels
(Downlinklink) dBm
Maximum Power
No. Tones 700 MHz Band12/17 700 MHz Band13 800 MHz 2100 MHz 1900 MHz
2 -10.8 -9.4 -6.3 2.0 -2.4
3 -14.3 -12.9 -9.8 -1.6 -5.9
4 -16.8 -15.4 -12.3 -4.1 -8.4
5 -18.7 -17.3 -14.2 -6.0 -10.3
6 -20.3 -18.9 -15.8 -7.6 -11.9
Noise Figure 3 dB nominal
Isolation > 90 dB
Power Requirements
5 V 2.5 A
Each Signal Booster is individually tested and factory set to ensure FCC compliance. The Signal Booster cannot be adjusted without factory
reprogramming or disabling the hardware. The Signal Booster will amplify, but not alter incoming and outgoing signals in order to increase coverage
of authorized frequency bands only. If the Signal Booster is not in use for five minutes, it will reduce gain until a signal is detected. If a detected
signal is too high in a frequency band, or if the Signal Booster detects an oscillation, the Signal Booster will automatically turn the power off on
that band. For a detected oscillation the Signal Booster will automatically resume normal operation after a minimum of 1 minute. After 5 (five) such
automatic restarts, any problematic bands are permanently shut off until the Signal Booster has been manually restarted by momentarily removing
power from the Signal Booster. Noise power, gain, and linearity are maintained by the Signal Booster’s microprocessor.
The Manufacturer’s rated output power of this equipment is for single carrier operation. For situations when multiple carrier signals are present, the
rating
would have to be reduced by 3.5 dB, especially where the output signal is re-radiated and can cause interference to adjacent band users.
This power reduction is to be by means of input power or gain reduction and not by an attenuator at the output of the device.
This device complies with Part 15 of FCC rules. Operation is subject to two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not
expressly approved by weBoost could void the authority to operate this equipment.
