Page #8 background imageLoading...
Page #8 background image
8
ENGLISH
Need help? www.weBoost.com
Customer Support 866-294-1660
Mon.- Fri. Hours: 7 am to 6 pm MST
Signal Booster Specifications
Drive 4G-S
Model Number 460022
Connectors SMA-Female
Antenna Impedance 50 Ohms
Frequency 698-716 MHz, 746-787 MHz, 824-894 MHz, 1850-1995 MHz, 1710-1755/2110-2155 MHz
Passband Gain (nominal)
700
MHz Band12/17
16.7
700MHz Band13
15.7
800MHz
16.0
1700/2100
MHz
15.7
1900
MHz
15.1
20 dB Bandwidth (MHz)
700
MHz Band12/17 700MHz Band13 800MHz 1700/2100MHz 1900MHz
Typical
Maximum
32.7
36.9
34.0
37.1
41.8
43.8
88.2
90.4
84.5
85.5
Power output for single cell
phone (Uplink) dBm
700
MHz Band12/17 700MHz Band13 800MHz 1700MHz 1900MHz
24.28 24.35 24.44 25.14 24.25
Power output for single cell
phone (Downlink) dBm
700
MHz Band12/17 700MHz Band13 800MHz 2100MHz 1900MHz
10.84 11.23 11.72 12.35 10.96
Power output for multiple
received channels (Uplink) dBm
No. Tones
700
MHz Band12/17 700MHz Band13 800MHz 1700MHz 1900MHz
2 24.8 22.5 20.7 21.4 22.5
3 21.2 19.0 17.1 17.9 18.9
4 18.7 16.5 14.6 15.4 16.4
5 16.8 14.6 12.7 13.5 14.5
6 15.2 13.0 11.1 11.9 12.9
Power output for multiple
received channels
(Downlinklink) dBm
No. Tones 700
MHz Band12/17 700MHz Band13 800MHz 2100MHz 1900MHz
2 13.0 12.9 13.5 12.5 10.9
3 9.4 9.4 10.0 9.0 7.4
4 6.9 6.9 7.5 6.5 4.9
5 5.0 4.9 5.5 4.6 2.9
6 3.4 3.4 3.9 3.0 1.3
Noise Figure 5 dB nominal
Isolation > 40 dB
Power Requirements 5.5 V 2 A
Each Signal Booster is individually tested and factory set to ensure FCC compliance. The Signal Booster cannot be adjusted without factory
reprogramming or disabling the hardware. The Signal Booster will amplify, but not alter incoming and outgoing signals in order to increase
coverage of authorized frequency bands only. If the Signal Booster is not in use for five minutes, it will reduce gain until a signal is detected.
If a detected signal is too high in a frequency band, or if the Signal Booster detects an oscillation, the Signal Booster will automatically turn
the power off on that band. For a detected oscillation the Signal Booster will automatically resume normal operation after a minimum of 1
minute. After 5 (five) such automatic restarts, any problematic bands are permanently shut off until the Signal Booster has been manually
restarted by momentarily removing power from the Signal Booster. Noise power, gain, and linearity are maintained by the Signal Booster’s
microprocessor.
The Manufacturers rated output power of this equipment is for single carrier operation. For situations when multiple carrier signals are
present, the rating would have to be reduced by 3.5 dB, especially where the output signal is re-radiated and can cause interference to
adjacent band users. This power reduction is to be by means of input power or gain reduction and not by an attenuator at the output of the
device.
