weBoost DRIVE SLEEK User Manual

2
CELL PHONE SIGNAL BOOSTER DRIVE SLEEK
______
Step 1: Mount Outside
Magnetic Antenna
NOTE: For roofs that are not metallic, use the included metal disk by peeling
away the adhesive cover and sticking on the clean surface.
6 in. away from windows
(including sunroofs)
WORKS WITH ALL VEHICLES
Identify a location on the top of your vehicle that is:
 Near the center of the roof
 At least 12 inches away from any other antennas
 At least 6 inches away from any windows
(including sunroofs)
Cle an the surface where you will place the outside
antenna.
Mount the outside antenna.

weBoost DRIVE SLEEK Specifications

General

Max Gain	23 dB
Connectors	SMA
Impedance	50 Ohms
Bands Supported	Band 12/17, Band 13, Band 5, Band 4, Band 2
Power Source	Vehicle 12V outlet
