(SPECIFICATIONS cont.)
Home 4G™
Model Number 470001
FCC ID PWO460001
IC 4726A-460001
Connectors SMA-Female on the Inside Antenna / F-Female on the Outside Antenna
Antenna Impedance 75 Ohms / 50 Ohms
Frequency 704-746 MHz, 746-787 MHz, 824-894 MHz, 1850-1995 MHz, 1710-1755/2110-2155 MHz
Passband Gain (nominal)
700 MHz
Band17
57.3
700 MHz
Band13
55.0
800 MHz
Band 5
57.2
1700/2100 MHz
Band 4
60.5
1900 MHz
Band 25/2
57.0
20 dB Bandwidth (MHz)
700 MHz
Band17
700 MHz
Band13
800 MHz
Band 5
1700/2100 MHz
Band 4
1900 MHz
Band 25/2
Typical
Maximum
26.2
29.8
26.7
29.8
38.3
39.5
73.5
73.8
78.4
80.1
Power output for single cell
phone (Uplink) dBm
700 MHz Band17
Band17
700 MHz Band13
Band13
800 MHz
Band 5
1700 MHz
Band 4
1900 MHz
Band 25/2
23.7 23.6 24.6 24.9 23.3
Power output for single cell
phone (Downlink) dBm
700 MHz Band17
Band17
700 MHz Band13
Band13
800 MHz
Band 5
2100 MHz
Band 4
1900 MHz
Band 25/2
0.9 -1.0 2.1 5.8 6.1
Power output for multiple
received channels (Uplink) dBm
No. Tones
Maximum Power
700 MHz Band17
Band17
700 MHz Band13
Band13
800 MHz
Band 5
1700 MHz
Band 4
1900 MHz
Band 25/2
2 21.3 20.7 23.0 19.9 18.1
3 17.7 17.2 19.4 16.4 14.6
4 15.2 14.7 16.9 13.9 12.1
5 13.3 12.8 15.0 11.9 10.2
6 11.7 11.2 13.4 10.4 8.6
Power output for multiple
received channels
(Downlinklink) dBm
Maximum Power
No. Tones
700 MHz
Band17
700 MHz
Band13
800 MHz
Band 5
2100 MHz
Band 4
1900 MHz
Band 25/2
2 -2.0 -3.2 1.8 -0.5 -2.2
3 -5.6 -6.7 -1.7 -4.1 -5.8
4 -8.1 -9.2 -4.2 -6.6 -8.3
5 -10.0 -11.2 -6.1 -8.5 -10.2
6 -11.6 -12.8 -7.7 -10.1 -11.8
Noise Figure 7 dB nominal
Isolation > 110 dB
Power Requirements AC / DC 5V, 2.5A, w/2.5x5.5mm Jack

weBoost Home 4G Specifications

General

Brand	weBoost
Model	Home 4G
Category	Extender
Language	English
