ig Series HMI Installation Manualig V2.0
2
Part 4 Basic Inspection
Please do following basic checking before using this series HMI.
General
 Check if each screw is loose.
 The vent hole should be protected from oil, water and metal powder, and the chip powder of the
drill should be prevented from falling into the HMI.
 If there are harmful gases or dust in the HMI operating environment, please take protective
measures.
Checking before installation (Unpowered)
 Please deal with connection division of wiring terminal insulated.
 Communication wiring should be correct, otherwise abnormal operation may occur.
 Check for foreign matter entering the interior of the HMI, especially for flammable substances and
conductive materials such as screws, metal sheets, etc.
 Please regulate instrument to reduce electromagnetism interference.
 Check HMI supply voltage.
Checking before running (powered)
 Check the status of the power indicator.
 Check if the communication between the HMI and the device is normal.
 If there is any abnormality in the HMI interface, please contact the manufacturer.
Part 5 Packing List
Sequence number
Component
Quantity
1
this series HMI
1
2
HMI LED
4
3
Power terminal
1
Part 6 Specifications
Module
Content
PI3070ig /
PI8070ig
PI3102ig /
PI8102ig
PI8150ig /
PI8150ig(N)
Power voltage
DC24V
Power voltage range
DC12V-DC28V
DC18V~DC28V
Permissible instantaneous
power failure time
<5ms
Power consumption
<8W
<10W
<15W
Operating ambient temperature
-10℃~+55℃
0℃~+50℃
Storage ambient temperature
-20℃~+70℃
-20℃~+60℃
Operating ambient humidity
10%~90%RH (Non-condensing)
Storage ambient humidity
10%~90%RH (Non-condensing)
Vibration resistance
Conforms to IEC61131-2 standard:
Continuous vibration:10Hz~57Hz 0.0755mm,57Hz~150Hz 9.8m/s²
Intermittent vibration:10Hz~57Hz 0.0035mm,57Hz~150Hz 4.9 m/s²
in each X, Y, Z direction 10 times (80 miunuties)
Corrosion resistance
Avoid corrosive gas
Cooling method
Natural air cooling
