Wega EPU Series User Manual

58 of 68
TECHNICIANS manual
14.7.8 Wiring diagram cod. WY18090018 - WY18090019
BI
White
BL
Blue
BA
Battery
CAB
Power cable
CAL
Boiler
CM
Membrane connection
CN1
Power supply and services
outputs
CN2
Not managed
CN3
Boiler level probe connect.
CN4
Programm. inter. connect.
CN5
connect. with display card
CO
Power switch
CT
Supply connector
CV1
Volumetric counter
GV
Yellow-green
IP
Programming switch
IST
Cup heater switch
LA
Indicator light
MA
Brown
MC
To machine
NE
Black
PLT
Tea button
PR
Pressure switch
RE
Resistance
RO
Red
RL
Relay
SA
Resistance safety device
SCB
Base card
SCD
Display card
SL
Boiler level probe
TG
Main remote switch
VE
Green
(
*
) Fuses for UL versions with plug with
a greater capacity than 30A
FIG. A
Base card - display card con-
nection detail
FIG. B
Jumpers inside view
JUMPER INSERTED NOT INSERTED
JP1
Volumetric counter
hardware
Dispensing volume software
default
CT
SCT
LA
PR
SA
CO
RE
400V
IST
R
S
T
N
MA
BL NE GR GV
CAB
MA
BL
FA5
FA4
FA2
FA1
CN1CN2CN3
CN4
IP
TG
SCB
CM
SCD
P2
P1
FA2
FA1
RL
BA
FIG. A FIG. B
MC
SL
CAL
13 9 5
1
3
71115
16 12 8
4
2
610
14
