Operation and Maintenance Manual for WP13 Series Diesel Engines
1
Product implementation standards:
Q/WCG134 WD10 Series Diesel Engines (for filing)
Q/WCG131 WP10 Series Diesel Engines (for filing)
GJBZ768A-1998 Guide for Fault Tree Analysis
GJB/Z3-1988 After-sales Technical Services for Military Products
GJB1443-1992 Quality Management Requirements for Product Packaging, Loading and Unloading,
Transport and Storage A.1
GJB/Z1391-2006 Guide for Analysis of Fault Mode Effects and Danger
GJB1107-1991 Maintainability Specifications for Military Vehicles
Chapter I Product Technical Survey
1.1 Diesel Engine Power and Speed
The WP13 engine has its power range and rated speed of 353 - 405 kW and 2100r/min respectively
(therein, WP13.480 has its rated speed of 1900r/min).
1.2 Main Structural Characteristics of the Diesel Engine
● One cylinder one head, reliable work and convenient disassembly
● Right-mounted common rail system (seen from the free end), convenient for arrangement of
the complete vehicle
● Frame main bearing structure, high overall rigidity, conducive to the reliability and service life
of the complete engine
● Mid-set supercharger, fewer dimensional changes of all types of the engine series
● Rear-set gear transmission, featuring a compact structure and low noise
● Inline six cylinders of the whole series, featuring a high degree of universality and convenient
for complete vehicle matching
1.3 Meanings of WP13 Series Diesel Engine Models
Variant number
Emission level
X
