18
38. Attach a Backrest (18) to the Front Upright (5)
with four M6 x 16mm Screws (67).
39. Attach another Backrest (18) to the Squat Frame
(9) with four M6 x 16mm Screws (67).
40. Press two 19mm Round Inner Caps (38) into a
Pad Tube (24). Insert the Pad Tube into the Leg
Lever (15). Slide two Small Foam Pads (27) onto
the Pad Tube.
Repeat this step with the other Pad Tube (24),
and the Front Leg (7).
38
39
40
5
18
9
18
67
67
67
67
7
38
38
24
24
15
27
27
