19
39. Attach the Front Backrest (41) to the Front
Upright (42) with two 1/4Ó x 2 1/2Ó Screws
(43) and two 1/4Ó Flat Washers (10). The
Backrest must be oriented as shown.
40. Press a 1 1/2Ó Square Inner Cap (32) into the
Front Seat Frame (36).
Insert a 1/4Ó x 2Ó Carriage Bolt (38) through
the center hole in the Seat Plate (37). Attach
the Seat Plate to the Seat (13) with two 1/4Ó x
1/2Ó Screws (18).
Insert the 1/4Ó x 2Ó Carriage Bolt (38) through
the indicated hole in the Front Seat Frame
(36). Tighten a 1/4Ó Nylon Locknut (2) with a
1/4Ó Flat Washer (10) onto the Carriage Bolt.
Attach the other end of the Seat (13) to the
Front Seat Frame (36) with a 1/4Ó Flat
Washer (10) and a 1/4Ó x 2Ó Machine Screw
(81).
41. Press a 1 1/2Ó Square Inner Cap (32) into the
Leg Lever (29).
Lubricate the 5/16Ó x 2 1/4Ó Bolt (33). Attach
the Leg Lever (29) to the Front Seat Frame
(36) with the Bolt and a 5/16Ó Nylon Locknut
(3).
Insert the 5/16Ó x 2Ó Eyebolt (35) into the Leg
Lever (29) from the direction shown. Tighten a
5/16Ó Nylon Locknut (3) with a 5/16Ó Flat
Washer (8) onto the Eyebolt.
42. Rest the Front Seat Frame (36) on the indi-
cated pin in the Front Upright (42). Attach the
Front Seat Frame to the Front Upright with a
5/16Ó x 2 3/4Ó Carriage Bolt (14) and the Seat
Knob (40).
42
39
41
Thick
End
42
40
41
SEAT ASSEMBLY
10
13
38
32
36
10
81
37
2
3
8
3
29
33
35
32
18
43
36
36
42
40
14
Pin
