M10 x 60mm Bolt (63)
M10 x 54mm Bolt (70)
M10 x 68mm Bolt (64)
M10 x 66mm Bolt (79)
M10 x 40mm Bolt (71)
M10 x 53mm Carriage Bolt (61)
M10 x 78mm Bolt (66)
M10 x 61mm Carriage Bolt (83)
M10 x 103mm Bolt (81)
M10 x 102mm Carriage Bolt (73)
M10 x 132mm Bolt (72)
M10 x 112mm Bolt (69)
M8 x 65mm Bolt (67)
M8 x 79mm Bolt (60)
M10 x 61mm Button Head Screw (85)
PART IDENTIFICATION CHART
Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST in the center of this manual. Note: Some small parts
may have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.
