19
USING THE LEG LEVER
Before using the low pulley station, engage the Leg
L
ever Pin (38) into the Leg Lever (8) and the Lock
Plate (73).
38
8
7
3
5
ARM CONVERSION
To use the Arms (9, 10) as butterfly arms, insert the
Arm Pins (40) into the holes in the Upright (3) and the
Pivot Frame (5) as shown.
To use the Arms (9, 10) as press arms, insert the Arm
Pins (40) into the holes in the Pivot Frame (5) and the
Arms.
40
3
9
Holes
13
61
14
7
30
USING THE CURL PAD
To use the Curl Pad (14), remove the 50mm Round
Inner Cap (30) from the Front Leg (7). Insert the Curl
Post (13) into the Front Leg and secure it in place
with the Curl Knob (61).
Before performing an exercise that does not require
the Curl Pad (14), remove the Curl Pad and press the
50mm Round Inner Cap (30) into the Front Leg (7).
Store the Curl Pad away from the weight system.
10
