1. VΩHz% , V
oltage, Ohms, Frequency, Duty cycle,
Capacitance, Diode Input Terminal
This is the positive input terminal for Voltage, Ohms, Frequency, Duty
cycle, Capacitance, Diode measurements.Connection is made to it
using the red test lead.
2. COM Co
mmon Terminal
This is the negative (ground) input terminal for all measurement modes
except current.Connection is made to it using the black test lead.
3. D
isplay
The display indicates the measured value of a signal, function mode,
and annunciator.
4.
RANGE
Button
The meter also has a manual range mode. In manual range, you
select and lock the meter in a range. To manually select a range:
Press [RANGE] button to hold the selected range.
Subsequently pressing the [RANGE] button will select each range i
n
s
equence from the lowest to highest range.
Hold the button for 2 seconds to return to the Autorange Mode.
5. ZERO Button
On the DC current ranges, the /ZERO button works as the zero mode,
and on other functions, the /ZERO button works as the relative mode.
Press REL button again to exit the mode.
Press Z
ERO button for more than 2 seconds to exit.
In the Relative mode, the value shown on the LCD is always the
difference between the stored reference value and the present
reading. For example, if the reference value is 24.00V and the present
reading is 12.50V, the display will indicate -11.50V. If the new reading
is the same as the reference value, the display will be zero.
6. F
unction/Range selector rotary switch
This rotary switch selects the fuction, and selects the desired range.
