Normal clamping
3.3.8 Profile depth, projection, max. cutting circle
The following table illustrates the relationship between
profile cutterhead, fitted cutter height, resultant profile
depth and maximum permissible cutting circle diameter.
3.3.9 Grinding
The blanks are profiled in accordance with a profile
template and ground in the profile cutterhead on a
Weinig grinder for profiled cutters.
3.3.10 Technical data
– Tool body of high-strength steel
– Optionally fitted with:
HSS (8 mm blank), Stellite / carbide (10 mm blank)
– Blank weight max. 50 g per 10 mm blank length
– Positive clamping of the profiled cutters with serrated
back, serration 1/16" x 60°
– Hardened clamping elements with ground clamping
area
– Cutting angle: 12° or 20°
– Diameter of tool body: 122/137 mm
– Max. speed: see legend on tool
Subject to change without notice!
Cutter height
[mm]
Max. permissible cutter cutting circle dia. [mm] for
profile cutterhead dia. [mm]
Max. possible
profile depth
[mm]
122 137
50 160 170 approx. 11
60 180 190 approx. 20
70 200 210 approx. 30
