Tech. Dok. / WNW 850 02 / 02.2005.A / © MICHAEL WEINIG AG Weinig Tools 3-19
Normal clamping
3.5.8 Profile depth, projection, max. cutting circle:
The following table illustrates the relationship between
profile cutterhead, fitted cutter height, resultant profile
depth and maximum permissible cutting circle diameter.
3.5.9 Grinding
The blanks are profiled in accordance with a profile
template and ground in the profile cutterhead on a
Weinig grinder for profiled cutters.
3.5.10 Technical data
– Tool body of high-strength steel
– For 2 or 4 profiled cutters 8 or 10 mm thick, with
serrated back
– Optionally fitted with HSS, stellite or carbide
– Blank weight max. 50 g per 10 mm blank length
– Positive clamping of the profiled cutters with serrated
back, serration 1/16" x 60°
– Hardened clamping elements with ground clamping
area
– Cutting angle: 12° or 20°
– Diameter of tool body: 137 mm or 122 mm
– Max. speed: n = 8,000 rpm
(see legend on tool)
Subject to change without notice!
Cutter height
[mm]
Max. permissible cutter cutting circle dia.
[mm] for profile cutterhead dia. [mm]
Max. possible
profile depth
[mm]
122 137
50 160 170 approx. 11
60 180 190 approx. 20
70 200 210 approx. 35
