Weishaupt WEM-RG2 User Manual

Installation and operating instruction
Room device WEM-RG2
4 Installation
83307102 2/2017-11 La
8-28
Fit wall bracket and connect
DANGER
Risk of electric shock
Working on the device when voltage is applied can lead to electric shock.
Isolate the device from the power supply prior to starting any work.
Safeguard against accidental restart.
The electrical connection must only be carried out by qualified electricians. Ob-
serve local regulations.
If only 2 wires are available on site, the connection can be made using the
adapter set WEM-CAN 2 wire (RG2) (accessory).
Secure wall bracket1 to the wall using the screws supplied.
Feed the wires2 through and connect to wiring diagram.
Hook in the room device at the top of the wall bracket3 and push to engage.
WEM-FA-G
H L – +
H L – +
2
1
3
