Weishaupt WTC-GB 25-B Compact User Manual

Installation and operating instruction
Gas condensing unit WTC-GB 15-B Compact and WTC-GB 25-B Compact
9 Servicing
83309302 1/2018-05 La
124-196
9.1.5 Cleaning the heat exchanger
Observe notes on servicing [ch.9.1.1].
Remove burner surface [ch.9.1.3].
Remove electrodes [ch.9.1.4].
Heat exchanger cleaning kit (accessory) required.
Insert cover plate1 from cleaning kit.
Heat exchanger is protected against falling dirt.
Clean combustion chamber with brush from cleaning kit and vacuum.
Remove cover plate.
1
1
Remove disc nuts from service cover3.
Remove service cover.
Remove gasket1 and clean seal groove2.
Clean heat exchanger with cleaning blades and brush from cleaning kit.
Vacuum out any dislodged dirt.
Clean sealing surfaces4.
1
2
3
4
4 Nm
