WEISS DSP501 User Manual

Weiss Enginering Ltd. DSP501/DSP502
Available Colours: Silver, Black
Digital Inputs
• (1) XLR connector
• (1) RCA connector
• (1) TOSLINK connector (optical)
• (1) USB type B connector
• (1) RJ45 Ethernet connector
→ All inputs accept professional or consumer standard, i.e. accept AES/EBU or S/PDIF signals.
Sampling frequencies
• AES/EBU and S/PDIF inputs:
– 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
• USB and RJ45 Ethernet inputs:
– 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz, 352.8 kHz, 384 kHz, DSD64, DSD128
• AES/EBU outputs:
– Sampling frequency selectable between 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
• Toslink input:
– 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Input word-length: max. 24 / 32 Bits
Digital Outputs
• (2) RCA Connectors
• (2) XLR connectors
→ RCA and XLR connectors each carry a stereo audio channel. Two stereo channels can be output.
Output sampling frequencies: selectable, internally generated
• Standard DSP50x unit: 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
• Low speed DSP50x unit: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Synchronization
Via the input signal in the case of the AES/EBU and S/PDIF inputs. Via the internal oscillator in the case of
USB and RJ45 inputs.
Analog Outputs: None
Headphone Output: None
User Manual and 20 White Papers
