Welbach ENTRIX 200D - Technical Specifications

2. Technical data
Parameter description
Parameter value
Product name TIG welder
Model
ENTRIX 200D
Nominal input voltage [V] / frequency [Hz]. 230~/50
Type of welding
MMA // TIG AC / DC
Welding current range MMA [A] 30-200
Welding current range TIG DC [A]
10-200
TIG AC welding current range [A] 10-200
Rated duty cycle
40%
Welding current in 100% duty cycle [A]
MMA: 126
TIG: 126
Welding current in 60% duty cycle [A]
MMA: 163
TIG: 163
Welding current in 40% duty cycle [A]
MMA: 200
TIG: 200
Idle voltage [V].
65
Efficiency [%] 80
MMA electrode diameter [mm]
1.6-4
TIG electrode diameter [mm] 1.2-2
Power factor
0.73
Arc force YES
Hot start
YES
Cooling Fan
Burner cooling
Gas
IP class IP21S
Insulation class
F
TIG welding thickness [mm] 0.5-5
MMA welding thickness [mm] 1-6
Compliance with standard EN 60974-1
Dimensions (width x depth x height) [cm] 46x22x37
Weight [kg] 19.6
