Welch Allyn SureTemp 4 Directions For Use

Fasten the 767 SureTemp 4 thermometer to the 76710 or
76720 wall transformer as follows:
1. Align the thermometer attachment plate within the
groove on the back of the main unit. Line up the
electrical contact blades with the corresponding blade
openings on the main housings.
BACK GROOVEATTACHMENT PLATE
CONNECTION BLADES
767 SURETEMP 4 MODULE MAIN UNIT
2. Slide the 767 SureTemp 4 thermometer into the main
unit until the gap between the devices is closed.
3. Secure the thermometer in place, as shown using the
two Philips head screws provided.
5
