BACK GROOVEATTACHMENT PLATE
CONNECTION BLADES
767 SURETEMP 4 MODULE MAIN UNIT
2. Slide the 767 SureTemp 4 thermometer into the main
unit until the gap between the devices is closed.
3. Secure the thermometer in place, as shown using the
two Philips head screws provided.
4. Install the assembled 767 transformer and thermom-
eter by fitting the keyholes in the wall transformer
backplate over the screw heads on the wall mounting
plate and pushing downward on the assembly to
secure it in place.
