TRIAC TYPE AUTOMATIC VOLTAGE REGULATOR
Model:
AVR-TRC-AGILE 1000/2000/3000/5000/10000-WL
7. MAINTENACE
This AVR is basically maintenance free! But regular maintenance can extend the life span of the AVR by the following
steps:
Regular inspection
• Disconnect the AVR from the mains power completely.
• Use cotton cloth and detergent to clean the body and ventilation holes.
• Check all the terminals, replace the abnormal one with that of the same specification.
Extraordinary inspection
• When malfunction occurs, or the AVR is abnormal, please measure and check the parameters, refer to the authorized
dealer if needed.
• In thunder and lightning or rainy season, Extraordinary Inspection should be executed to prevent malfunction.
• Maintenance should not be operated when AVR is working.
8. TROUBLE SHOOTING
Code Code Status AVR Status
What to do
Flashing
OUTPUT VOLTAGE
Flashing
OUTPUT VOLTAGE
Steady
OUTPUT VOLTAGE
Steady
OUTPUT VOLTAGE
Steady
OUTPUT VOLTAGE
Flashing
OUTPUT VOLTAGE
Flashing
OUTPUT VOLTAGE
Steady
OUTPUT VOLTAGE
Flashing
Remove unnecessary
appliances
Wait till input frequency
backs to normal range
45-65Hz
Wait till the countdown
is finished
Wait till input voltage
increases to normal
range
Wait till input voltage
decreases to normal
range
Wait till the temperature
of Triac decreases
to normal range
Wait till the temperature
of transformer
decreases
to normal range
Contact the dealer
Remove unnecessary
appliances connected;
if still not solved, contact
the dealer
OUTPUT VOLTAGE
Overload protection
Protection of out of
frequency
Countdown time
in minute for a
retry to restart
AVR once an
overload happened
Input under voltage
protection
Input over voltage
protection
Over temperature
protection for
Triac
Over temperature
protection for
transformer
Output voltage is out
of range while input
voltage is within
normal range
AVR is heavily
overloaded like
4-5 times
10
