Well AVR-TRC-AGILE-1000-WL User Manual

5
TRIAC TYPE AUTOMATIC VOLTAGE REGULATOR
Model:
AVR-TRC-AGILE 1000/2000/3000/5000/10000-WL
Delivered pack includes:
AVR 1 piece
User’s manual
Warranty card
A. visual observation
a. Check the name plate to verify the rated capacity is according to your purchase order.
b. Make sure appearance of the AVR is not damaged. If you notice any damage, contact the transport firm and
the authorized dealer.
Do not try to operate the AVR in this situation!
Do not try to repair the AVR by yourself!
4. Introduction of the AVR
Familiarize yourself with the various features
and facilities by studying the two diagrams
below to obtain maximum benefit from the
regulator.
Front of the Regulator 500/5000VA model
LED INDICATORS
Green LED: power on
Yellow LED: delaying
Red LED: protecting
Input Voltage
Output Voltage
ON
OFF
1 piece
1 piece
ON BYPASS ON
OFF BYPAS S OFF
Outpu t Voltage
Input Vo ltage
Front of the Regulator10,000VA model

Well AVR-TRC-AGILE-1000-WL Specifications

General

Brand	Well
Model	AVR-TRC-AGILE-1000-WL
Category	Controller
Language	English
