Well EAGLE - Technical specifications; Indoor unit specifications; Outdoor unit specifications

Indoor unit
Screen size
7"
Resolution
800(H)×480(W)
Effective area
154.08 (H)×86.58 (W)mm
Dot pitch
0.0642(W)×0.1790(H)mm
Outline size
214(W)X152(H)X18(D)mm
Adapter input voltage
AC100-240V 50Hz/60Hz
Adapter output
voltage&current
DC24V 1A
Monitoring time
30S±10
Talking time
60S±10
Power consumption
Static state <0.2W Working state <5W
Operating temperature
-20℃～+50℃
Relative humidity
10 ～90 （RH）
Outdoor unit
Night Vision
White (Standard)
Red (For option)
Operating Temperature
-20 ℃ ～ +50 ℃
Illumination
0.1LUX
Resolution
700 TV lines (CMOS)
Viewing Angle
69°wide angle (CMOS)
Size (with rain cover)
65(W)×154(H)×46(D)mm
Size (without rain cover)
58(W)×145(H)×30(D)mm
Instrucțiuni de utilizare
Technical specifications
Protecție împotriva ploii
Lumină pentru vedere pe timp de noapte
Cameră
Difuzor
Plăcuță nume/cititor
Buton apelare
Microfon
Unitatea exterioară
