Weller WS 80 - Accessories; Scope of Supply; Warnings

24
6. Accessories
5 29 161 99 Soldering iron set WSP 80 (WS 80 only)
5 33 110 99 Soldering iron set MPR 30
5 33 111 99 Soldering iron set MLR 21
5 33 112 99 Soldering iron set LR 21, antistatic
5 33 113 99 Soldering iron set LR 82 (WS 80 only)
5 33 133 99 Soldering iron set WTA 50
5 13 050 99 Reflow soldering unit EXIN 5
5 27 028 99 Preheating plate WHP 80 (WS 80 only)
5 25 030 99 Thermal insulating unit WST 20
7. Scope of supply
WS 80 WS 50 PU 80 / PU 50
Control unit Control unit Control unit
Soldering iron WSP 80 Soldering iron LR 21 Power cable
Power cable Power cable Operating instructions
Operating instructions Operating instructions Jack
Soldering iron rest Soldering iron rest
Jack Jack
Illustration: Circuit diagram, see Page 55 + 56
Illustration: Exploded view, see Page 53+54
8. Warnings
1. Keep your work area in proper order.
Always return the soldering tool to its original holder when not in use. Do not bring
combustible materials near the hot soldering tools.
2. Take care for the surroundings.
Don't use the soldering tool in a moist or wet environment.
3. Protect yourself against electrical shocks.
Avoid touching grounded parts with your body, e.g. pipes, heating radiators, stoves,
refrigerators.
4. Keep children at a distance.
Don't allow other persons to touch or disturb the soldering tool or cord. Keep other
persons away from your work area.
5. Store your soldering tool in an appropriate place
Unused soldering tools should be stored in a dry location which is out of the reach of
children (some place high or in a locked cabinet). Switch off all unused soldering tools.
6. Do not overload your soldering tool.
Use the soldering tool only with the specified voltage or specified pressure and pressure
range.
7. Use the appropriate soldering tool.
Don't use a soldering tool whose performance is not adequate for your work. Never
use the soldering tool for purposes for which is was not designed.
8. Wear suitable work cloths.
There is a danger of burning yourself with liquid solder. Wear the corresponding
protective clothing in order to protect yourself against burns.
9. Protect your eyes.
Wear protective eyewear. When working with bonding agents, it is particularly important
to observe the warning notices of the bonding agent manufacturer. Protect yourself
against spattering solder. There is a danger of burning yourself with liquid solder.
10. Use a soldering vapour suction device
If devices for solder vapour suction are available, ensure that these are connected and
correctly used.
11. Do not use the cord for purposes for which it is not designed.
Never carry the soldering tool by the cord. Don't use the cord to pull the power plug
from the socket. Protect the cord from heat, oil, and sharp edges.
