Wen 20716BT

EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
1 DT1315-001 Front Hub Cap 2
2 DT1315-002 Front Wheel Washer 4
3 DT1315-005 Front Wheel 2
4 DT1315-038 Front Wheel Pin 4
5 20716-005
Self-tapping Screw,
ST4x20
13
6 20716-006 Front Axle Plate 2
7 DT1315-004 Front Axle 1
8 20716-008
Self-tapping Screw,
ST4x16
18
9 20716-009
Right Depth
Adjustment Handle
1
10 20716-010
Left Depth Adjustment
Handle
1
11 20716-011 Socket Cap Screw, M6x12 1
12 20716-012 Blade Bracket Arm 1
14 20716-014
Self-tapping Screw,
ST5x25
3
15 20716-015 Screw, M5x25 1
16 20716-016 Blade Bearing Bracket 1
17 20716-017 Lock Nut, M5 1
18 20716-018
Self-tapping Screw,
ST4x12
3
19 20716-019 Front Grill 1
20 20716-020
Counterweight
Mounting Bracket
1
21-1
20716-021
Counterweight 1
Assembly
121-2
21-3
22 20716-022 Air Filter 2 1
23 20716-023
Self-tapping Screw,
ST4x20
2
24 20716-024 Air Filter 1 1
26 20716-026
Self-tapping Screw,
ST5x25
2
27 DT1315-022 Rear Wheel Axle Pin 2
28 DT1315-024 Rear Wheel 2
30 DT1315-026 Rear Hub Cap 2
31 20716-031 Square Nut, M8, 12x12x6 2
32 20716-032 Cable Clamp 1
33 20716-033 Exhaust Cover A 1
35 20716-035 Exhaust Cover B 1
36 20716-036 PCB 1
37 20716-037 PCB Mounting Bracket 1
38 20716-038 Housing 1
NO. PART NO. DESCRIPTION QTY.
39 20716-039 Housing Cover 1
40-1
20716-040 Safety Key Assembly
1
40-2 2
40-3 4
41-1
20716-041 Safety Key Lock
1
41-2 1
42 20716-042 Battery Cover 1
43 20716-043 Battery Cover Pin 1
44 20716-044 Battery Cover Spring 1
45 20716-045 Screw, ST4x12 2
46 20716-046 Handle Cover 1
47 20716-047 Handle 1
48 20716-048 Grass Bag Cover 1
49 20716-049 Grass Bag Cover Pin 1
50 20716-050 Grass Bag Cover Spring 1
51 20716-051 Spring Retaining Pin 1
52 DT1315-040 Grass Bag 1
53 DT1315-039 Grass Bag Frame 1
54 20716-054 Screw, M8x50 2
55 20716-055
Handle Height Adjustment
Knob
2
56 20716-056
Self-tapping Screw,
ST4.8x14
6
57 DT1315-051 Lower Handle Rod 2
58 20716-058 Lower Handle Bracket 2
59 DT1516-038 Lower Locking Knob 4
60 DT1516-039 Pin 4
61 DT1516-032 Locking Knob Washer 4
62 DT1315-046 Middle Handle Frame 1
63 DT1315-044
Handle Frame Carriage
Bolt, M6-0.75x53
4
64 DT1315-049B Hex Wrench Clip 2
65 20716-065 Grill Retainer Clip 2
66-1
20716-066
Counterweight 2
Assembly
166-2
66-3
67 DT1315-031 Hex Wrench, 5mm 1
100 20716-100ASM Motor Assembly 1
101 20716-101 Motor 1
102 20716-102 Pinion 1
103 20716-103
Flexible Shaft Washer,
6mm
1
104 20716-104 Gearbox 1
105 20716-105 Screw, M5x16 4
20
