Wen 20716BT

EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
106 20716-106 Bearing, 608-2RS 1
107 20716-107
Flexible Shaft Washer,
12mm
1
108 20716-108 Motor Gear 1
109 20716-109 Key, 3x3x10 1
110 20716-110 Large Gearshaft 1
111 20716-111 Bearing, 6001-ZZ 1
112 20716-112 Pulley Support 1
113 20716-113 Small Pulley 1
115 20716-115 Gasket 1
116 20716-116 Output Shaft 1
117 20716-117 Bearing, 6002-2RS 1
118 DT1315-124 Drive Belt, EPJ350 1
119 20716-119 Large Pulley 1
120 20716-120 Bearing, 6000-2RS 1
121 20716-121 Lock Nut, M8 1
122 20716-122 Bracket Cover 1
123 20716-123
Self-tapping Screw,
ST4x18
8
124 20716-124 Bearing, 608-ZZ 1
125 20716-125 Gasket 1
126 20716-126 Wear Pad 4
127 20716-127 Roll Pin 1
200 20716-200ASM Battery Terminal 1
201 20716-201
Battery Pack Insert Pres-
sure Plate
2
202 20716-202 Board 1 1
8 20716-8
Self-tapping Screw,
ST4x16
4
45 20716-45
Self-tapping Screw,
ST4x12
4
203 20716-203 Board 2 2
204 20716-204 Board 3 1
400 20716-400ASM Handle Assembly 1
401 20716-401 Trigger Seat, Left 1
402 20716-402 Spring 1
403 20716-403 Connecting Rod 1
404 20716-404 Trigger Seat, Right 1
405 20716-405
Self-tapping Screw,
ST4x25
2
406 20716-406 Pressure Plate 1
407 20716-407 Switch Housing, Left 1
408 20716-408 Switch Plug Head 1
409 20716-409 Wire 1
NO. PART NO. DESCRIPTION QTY.
411 20716-411 Rocker Switch 1
412 20716-412 Spring 1
413 20716-413 Trigger 1
414 20716-414 Switch Button 1
415 20716-415 Switch Housing, Right 1
416 20716-416 Upper Handle Tube 1
417 20716-417 Upper Handle Grip 1
418 20716-418 Trigger Handle 1
5 20716-005
Self-tapping Screw,
ST4x20
3
32 20716-032 Cable Clamp 2
123 20716-123
Self-tapping Screw,
ST4x18
8
500 DT1315-300
Scarifier Blade
Assembly
1
501 DT1315-301 Bearing Shaft 1
502 DT1315-302 Bearing Shaft Washer 1
503 DT1315-303 Bearing Shaft Collar 1
504 DT1315-304 Set Pin 1
505 DT1315-305 Scarifier Blade 8
506 DT1315-306 Plastic Shaft Collar 7
507 DT1315-307 Shaft Collar 1
508 DT1315-308 End Cap 1
509 DT1315-309 Blade Rod Washer 1
510 DT1315-310 Blade Rod 1
511 DT1315-311 Circlip, 10mm 1
120 DT1315-127 Bearing, 6000-2RS 1
600 DT1315-400
Dethatcher Blade As-
sembly
1
601 DT1315-401 Blade Rod Divider 13
602 DT1315-402 Scraper Tine Mount 11
603 DT1315-403 Scraper Tine 24
604 DT1315-404 Blade Rod 1
120 DT1315-127 Bearing, 6000-2RS 1
501 DT1315-301 Bearing Shaft 1
502 DT1315-302 Bearing Shaft Washer 1
508 DT1315-308 End Cap 1
511 DT1315-311 Circlip, 10mm 1
605 DT1315-405 End Scraper Tine Mount 1
606 DT1315-407 Steel Washer 1
607 DT1315-406
Bearing Shaft Washer,
Thin
1
21
