EXPLODED VIEW & PARTS LIST
8
7
6
5
4
3
2
1
11
10
13
9
12
14
No. Part No. Description Qty.
1 21C-001 Carbide Bit 1
2 21D-002 Lock Cap 1
3 21D-003 Shaft Assembly 1
4 21D-004 Shaft 1
5 21D-005 Pin 1
6 21D-006 Housing 1
7 21D-007 Spring 1
8 21D-008 Depth Adjustment Knob 1
9 21D-009 Oscillator 1
10 21D-010 Power Switch 1
11 21D-011 Power Cord 1
12 21D-012 Screw, ST2.9x12 3
13 21C-002 Hex Wrench, 1.5 mm 1
14 21C-003 Socket-Head Screw, M3-0.5x4 1
To Next Page
