Wen 3403 - Page 13

EXPLODED VIEW AND PARTS LIST
No. Parts No. Description Qty.
1 3403-001 Caster 4
2 3403-002 Nut M8 6
3 3403-003 Base Plate 1
4 3403-004 Washer ø8 28
5 3403-005 Motor Base 1
6 3403-006 Hex Screw M8x16 18
8 3403-008 Motor 1
9 3403-009 Switch 1
10 3403-010
Hex Wrench M6
(for No. 40)
1
11 3403-011
Hex Wrench M5
(for No. 26)
1
13 3403-013 Upper Bag Support 1
15 3403-015 Hex Screw M6x20 6
16 3403-016 Washer ø6 28
17 3403-017 Key A5x25 1
18 3403-018 Packing 1
19 3403-019 Nut M6 22
20 3403-020 Spring Washer ø10 4
21 3403-021 Hex Screw M10x16 4
22 3403-022 Turbo Fan 1
23 3403-023 Screw M6x10 28
24 3403-024 Inlet 1
25 3403-025 Inlet Cover 1
26 3403-026 Hex Screw M6x20 (left) 1
27 3403-027 Washer 1
29 3403-029 Outlet Gasket 1
NOTE: Parts that wear down over the course of normal use are not covered by the two-year warranty. Repairs
and replacements should only be performed by an authorized technician.
No. Parts No. Description Qty.
30 3403-030 Outlet 1
31 3403-031 Hose Clamp 2
32 3403-032 Hose ø125x75mm 1
33 3403-033 Collector 1
34 3403-034 Bag Clamp 2
35 3403-035 Filter Bag 1
36 3403-036 Collector Bag 1
37 3403-037 Collector Support 3
39 3403-039 Handle 1
40 3403-040 Hex Screw M8x20 2
41 3403-041 Hex Screw M8x25 4
42 3403-042 Fan Housing 1
43 3403-043 Packing 1
44 3403-044 Cap Screw 1
45 3403-045 Cover 1
46 3403-046 Switch Box 1
47 3403-047 Screw ST4.2x13 2
48 3403-048 Screw ST4x60 4
49 3403-049 Plug and Cord 1
50 3403-050
Current Overload
Protector
1
51 3403-051
Capacitor 1
(80uf/250V)
1
52 3403-052
Capacitor 2
(400uf/125V)
1
53 3403-053 Capacitor Cover 2
54 3403-054 Screw 4
13
