Wen 3410 Manual

11
EXPLODED VIEW & PARTS LIST
No. Part Number Description Qty.
39 90243-039 Fuse Holder 1
40 90243-040 Fuse Cap 1
41 90243-041 Fuse (2A) 1
42 3410-042RF Control Panel Label RF 1
43 90243-043 Screw M3X15 1
44 90243-044 Screw M3X30 1
45 90243-045 Screw ST3.2X8 1
46 3410-046RF-01 RF Printed Circuit Board 1
47 90243-047 Switch Box 1
48 90243-048 Flat Washer M3 2
49 90243-049 Lock Washer M3 2
50 90243-050 Hex Nut M3 2
51 90243-051 Wire 1
As02 90243-AS02 Motor & Fan Assembly 1
52 90243-052 Fan Wheel 1
53 90243-053 Fan Housing Cover 1
54 90243-054 Fan Housing 1
55 90243-055 Rubber Spacer 4
56 90243-056 Large Washer M5 4
57 90243-057 Lock Nut M5 4
58 90243-058 Motor 1
59 90243-059 Capacitor Cover 1
60 90243-060 Capacitor 1
61 90243-061 Fan Housing Cover 1
62 90243-062 Screw M5X25 4
63 90243-063 Hanger 4
64 90243-064 Flange Nut M6 4
65 90243-065 Chain 4
69 90243-069 Switch Box Cover 1
72 90243-072 Wood Screw Hook 4
No. Part Number Description Qty.
1 90243-001 Hex Nut M4 13
2 90243-002 Flat Washer M4 13
3 90243-003 Lock Washer M4 13
4 90243-004 Screw M4X12 5
5 90243-005 Screw M6X16 6
6 90243-006 Air Box Front Cover 1
7 90243-007 Grid Plate 1
8 90243-008 Air Guide 1
9 90243-009 Hex Nut M6 6
10 90243-010 Flat Washer M6 6
11 90243-011 Lock Washer M6 6
12 90243-012 Screw M4X12 8
13 90243-013 Screw ST4X10 34
14 90243-014 Air Box 1
15 90243-015 Screw M6X12 4
16 90243-016 Carrying Handle 1
17 90243-017 Handle Bracket 1
18 90243-018 Screw M5X16 2
19 90243-019 Flat Washer M5 3
20 90243-020 Lock Washer M5 3
21 90243-021 Hex Nut M5 6
22 90243-022 Screw M5X12 1
23 90243-023 Lock Washer M5 2
24 90243-024 Wire 1
25 90243-025 Grid Plate 1
26 90243-026 Inner Filter 1
27 90243-027 Outer Filter 1
28 90243-028 Rubber Foot 4
29 3410-029RF-01 RF Remote Control Unit 1
As01 90243-AS01 Control Panel Assembly 1
36 90243-036 Power Cord 1
37 90243-037 Strain Relief 1
38 90243-038 Screw M5X20 1
