Wen 4210

TABLE OF CONTENTS
Technical Data
2
3
4
5
7
8
16
17
19
20
22
General Safety Rules
Specific Safety Rules For Drill Press
Electrical Information
Know Your Drill Press
Assembly and Adjustments
Operation
Maintenance
Exploded View and Parts List
Warranty
TECHNICAL DATA
2
Troubleshooting
Motor:
Chuck Capacity:
Spindle Stroke:
Spindle Taper:
Speeds:
Swing:
Table Size:
Base Size:
Column:
Total Height:
Laser:
Weight:
120V, 60Hz, 375W, 3.2A
1/2 inch
2-1/2 inches
JT33
600, 1100, 1700, 2400, 3100 RPM
10 inches
7-5/8 x 7-5/8 inches
13-1/8 x 8-1/8 inches
2-1/4 inches
26-1/2 inches
CLASS II, 650nm, 1mW
51 lbs.
