Wen 4210

21
EXPLODED VIEW & PARTS LIST
Part # Description Qty Part # Description Qty
4210B-001 V-belt 1 4210B-055 Connecting Terminal 2
4210B-002 Motor Pulley 1 4210B-056 Knob 3
4210B-003 Set Screw 2 4210B-057 Feeding Handle 3
4210B-004 Power Cord 1 4210B-058 Gear Shaft 1
4210B-005 Spindle Pulley 1 4210B-059 Laser 2
4210B-006 Set Screw 2 4210B-060 Set Screw 2
4210B-007 Belt House Knob 1 4210B-061 Rivet 2
4210B-008 Belt House 1 4210B-062 Depth Scale 1
4210B-009 Flat Washer 1 4210B-063 Wing Screw 1
4210B-010 Nut 1 4210B-064 Depth Stop Ring 1
4210B-011 Hex Nut 3 4210B-065 Wing Screw 1
4210B-012 Cord Clamper 3 4210B-066 Spring 1
4210B-013 Retaining Ring 1 4210B-067 Pushing Shaft 1
4210B-014 Sleeve 1 4210B-068 Cap 1
4210B-015 Retaining Ring 1 4210B-069 Hex Head Bolt 4
4210B-016 Ball Bearing 1 4210B-070 Flat Washer 4
4210B-017 Ball Bearing 1 4210B-071 Motor Support 1
4210B-018 Retaining Ring 1 4210B-072 Hex Nut 2
4210B-019 Pan Head Screw 2 4210B-073 Flat Washer 4
4210B-020 Laser Battery house 1 4210B-074 Hex Head Bolt 2
4210B-021 AAA battery 2 4210B-075 Motor 1
4210B-022 Connecting terminal 2 4210B-076 Lock Washer 4
4210B-023 Flat Washer 3 4210B-077 Chuck Key Seat 1
4210B-024 Pan Head Screw 3 4210B-078 Pan Head Screw 1
4210B-025 Pan Head Screw 4 4210B-079 Flat Washer 1
4210B-026 Flat Washer 4 4210B-080 Hex Nut 2
4210B-027 Rubber Washer 4 4210B-081 Hex Nut 1
4210B-028 Bushing 3 4210B-082 Support Plate 1
4210B-029 Set Screw 2 4210B-083 Flat Head Screw 2
4210B-030 Head 1 4210B-084 Light Bulb Holder 1
4210B-031 Spring 1 4210B-085 Pan Head Screw 1
4210B-032 Spring Cap 1 4210B-086 Light Bulb 1
4210B-033 Hex Nut 2 4210B-087 Worm Shaft 1
4210B-034 Hex Nut 1 4210B-088 Table Locking Handle 1
4210B-035 Set Screw 1 4210B-089 Rivet 2
4210B-036 Switch Box 1 4210B-090 Angle Scale 1
4210B-037 Switch Plate 1 4210B-091 Table Support 1
4210B-038 Thread Forming Screw 3 4210B-092 Table 1
4210B-039 Switch 1 4210B-093 Washer 1
4210B-040 Pan Head Screw 2 4210B-094 Hex Head Bolt 1
4210B-041 Lock Washer 2 4210B-095 Column Collar 1
4210B-042 Serrated Washer 2 4210B-096 Set Screw 1
4210B-043 Pan Head Screw 4 4210B-097 Worm Gear 1
4210B-044 Light Switch 1 4210B-098 Pin 1
4210B-045 Depth Pointer 1 4210B-099 Retaining Ring 1
4210B-046 Rivet 1 4210B-100 Table Adjusting Handle 1
4210B-047 Pin 1 4210B-101 Socket Head Bolt 1
4210B-048 Rubber Washer 1 4210B-102 Rack 1
4210B-049 Retaining Ring 1 4210B-103 Column 1
4210B-050 Ball Bearing 1 4210B-104 Hex Head Bolt 4
4210B-051 Quill 1 4210B-105 Column Support 1
4210B-052 Ball Bearing 1 4210B-106 Base 1
4210B-053 Spindle 1 4210B-107 Wrench 2
4210B-054 Chuck with Key 1
