Wen 4210

TABLE OF CONTENTS
Specifications ............................................................................................ 2
Introduction .............................................................................................. 3
General Safety Rules ................................................................................. 4
Specific Safety Rules for the Drill Press .................................................... 5
Electrical Information ................................................................................ 8
Know Your Drill Press ............................................................................... 9
Assembly & Adjustments ........................................................................ 10
Operation ................................................................................................ 19
Maintenance ............................................................................................ 21
Troubleshooting Guide ............................................................................ 22
Exploded View & Parts List ..................................................................... 24
Warranty Statement ................................................................................ 27
SPECIFICATIONS
Model Numbers 4210, 4210T
Motor 120 V, 60 Hz, 3.2A
Chuck Capacity 1/2"
Spindle Stroke 2-1/2"
Spindle Taper JT33
Speeds 600, 1100, 1700, 2400, 3100 RPM
Swing 10"
Table Size 7-5/8 x 7-5/8"
Base Size 13-1/8 x 8-1/8"
Column Diameter 2-1/4"
Total Height 26-1/2"
Laser Class II, 650nm, 1mW
Weight 51 lbs.
2
Various drill bits, vises, clamps and other accessories can be purchased from
wenproducts.com.
