Wen 4212 User Manual

ASSEMBLY & ADJUSTMENTS
EXPLODED VIEW & PARTS LIST
25
No. Part No. Description Qty
1 4212B-001 Retaining Plate 1
2 4212B-002 Set Screw, M8x12 1
3 4212B-003 Cam 1
4 4212B-004 Ball Bearing, 6907Z 1
5 4212B-005 Elastic Ring 1
6 4212B-006
Spindle Moveable
Pulley
1
7 4212B-007 Spindle Fixed Pulley 1
8 4212B-008 Key, A Type, 4x4x64 1
9 4212B-009 Shaft Sleeve 1
10 4212B-010 Ball Bearing, 6203RZ 2
11 4212B-011 Retainer 1
12 4212B-012 Circlip, Ø17 1
13 4212B-013 V-Belt, Z-800 1
14 4212B-014 Circlip, Ø14 1
15 4212B-015 Motor Fixed Pulley 1
16 4212B-016 Motor Movable Pulley 1
17 4212B-017 Hex Screw 4
18 4212B-018
Motor Compression
Spring
1
19 4212B-019 Key, A Type, 4x4x84 1
20 4212B-020 Spring Base 1
21 4212B-021 Spring Washer 1
22 4212B-022 Screw, M5x12 3
23 4212B-023 Cord Clamp 3
24 4212B-024 Screw, M6x12 4
25 4212B-025 Pulley Cover Assembly 1
26 4212B-026 Rubber Bushing 2
27 4212B-027 Handle Knob 4
28 4212B-028 Handle Shaft 3
29 4212B-029 Handle Fixed Piece 1
30 4212B-030 Spring Pin, 6-15 2
31 4212B-031 Hex Screw, M8x8 2
32 4212B-032 Speed Sensor 1
33 4212B-033 Speed Sensor Base 1
34 4212B-034 Screw, M5x6 1
35 4212B-035 Screw, S2.9x6 2
36 4212B-036 Laser Switch 1
No. Part No. Description Qty
37 4212B-037 Battery Housing Cover 1
38 4212B-038 Battery Housing 1
39 4212B-039 Handle Seat 1
40 4212B-040 Spring Pin, 5-15 1
41 4212B-041 Feed Shaft 1
42 4212B-042 Depth Locking Knob 1
43 4212B-043 Scale Collar 1
44 4212B-044 Screw, M6x12 1
45 4212B-045
Digital Readout
Display
1
46 4212B-046 Switch Box 1
47 4212B-047 Switch Plate 1
48 4212B-048 Screw, ST4.9x16 2
49 4212B-049 Terminal 1
50 4212B-050 Screw, ST4.2x10 3
51 4212B-051 ON / OFF Switch 1
52 4212B-052 Flange Screw, M5x12 1
53 4212B-053 Screw, M5x8 2
54 4212B-054 Toothed Washer, M5 2
55 4212B-055 Spindle Circlip 1
56 4212B-056 Ball Bearing, 6201Z 2
57 4212B-057 Rubber Washer 40mm 1
58 4212B-058 Quill 1
59 4212B-059 Spindle, JT33 1
60 4212B-060 Chuck, JT33 1
61 4212B-061 Chuck Key 1
62 4212B-062 Rack Shaft 1
63 4212B-063 Rack Shaft Spring 1
64 4212B-064 Washer, M8 1
65 4212B-065 Hex Flange Bolt 1
66 4212B-066 Laser 2
67 4212B-067 Collar 1
68 4212B-068 Internal Gear 1
69 4212B-069 Worm Gear 1
70 4212B-070 Table Support 1
71 4212B-071 Crank Handle 1
72 4212B-072 Inner Gear Shaft 1
