ASSEMBLY & ADJUSTMENTS
EXPLODED VIEW & PARTS LIST
No. Part No. Description
92 4212B-092 Hex Nut, M10 1
93 4212B-093 Washer 4
94 4212B-094 Head 1
95 4212B-095 Flat Washer, M8 4
96 4212B-096 Motor Plate 1
97 4212B-097 Spring Washer, M8 3
98 4212B-098 Hex Bolt, M8x10 3
99 4212B-099 Spring Washer, M12 1
100 4212B-100 Capacitor Cover 1
101 4212B-101 Capacitor 1
102 4212B-102 Flat Washer, M4 2
103 4212B-103 Screw, M4x6 2
104 4212B-104 Circlip for Shaft Ø35 1
105 4212B-105 Hex Wrench, M3 1
106 4212B-106 Hex Wrench, M4 1
107 4212B-107 Manual 1
108 4212B-108 Power Cord 1
109 4212B-109 AA Battery 2
110 4212B-110 Screw, M4x8 1
111 4212B-111 Screw, M5x8 2
112 4212B-112 Counter Base 1
26
No. Part No. Description Qty
73 4212B-073 Table Lock Handle 1
74 4212B-074 Table 1
75 4212B-075 Hex Bolt, M12x25 1
76 4212B-076 Rack 1
77 4212B-077 Column 1
78 4212B-078 Hex Bolt, M8x25 3
79 4212B-079 Column Base 1
80 4212B-080 Base 1
81 4212B-081
Quill Set Screw,
M8x20
1
82 4212B-082 Hex Nut, M8 5
83 4212B-083 Coil Spring Assembly 1
84 4212B-084 Hex Nut, 3/8x24 UNF 2
85 4212B-085 Gear Shaft 1
86 4212B-086 Key, A Type, 3x3x25 1
87 4212B-087
Speed Adjustment
Base
1
88 4212B-088
Phillips-head Screw,
M5x25
3
89 4212B-089
Variable Speed Handle
Seat
1
90 4212B-090 Variable Speed Handle 1
91 4212B-091 Butterly Spring 1
