SPECIFICATIONS
Model Number 56035T
Compaction Force 4,496 lbs.
Compaction Pressure 1,498.66 lb. / ft.²
Plate Size 24 in. x 18 in.
Forward Travel Up to 82 ft. / min.
Vibration Speed 5400 BPM
Product Dimensions 25 in. x 18.5 in. x 27.5 in.
Product Weight 207 lbs.
PLATE COMPACTOR
Engine Type 4 stroke, OHV, Single Cylinder with Forced Air Cooling System
Engine Displacement 212cc
Ignition System Non-Contact Transistor
Fuel Tank Capacity 1 Gal.
Engine Oil Capacity 20 fl. oz. (0.6 L)
Spark Plug Torch F6TC (NGK BP6ES)
Spark Plug Gap 0.6mm - 0.8mm (0.023 in. - 0.031 in.)
ENGINE
INTRODUCTION
Thanks for purchasing the WEN Plate Compactor. We know you are excited to put your tool to work, but first, please
take a moment to read through the manual. Safe operation of this tool requires that you read and understand this
operator’s manual and all the labels affixed to the tool. This manual provides information regarding potential safety
concerns, as well as helpful assembly and operating instructions for your tool.
NOTE: The following safety information is not meant to cover all possible conditions and situations that may occur.
WEN reserves the right to change this product and specifications at any time without prior notice.
At WEN, we are continuously improving our products. If you find that your tool does not exactly match this manual,
please visit wenproducts.com for the most up-to-date manual or contact our customer service at 1-847-429-9263.
Keep this manual available to all users during the entire life of the tool and review it frequently to maximize
safety for both yourself and others.
Indicates danger, warning, or caution. The safety symbols and the explanations with them deserve your
careful attention and understanding. Always follow the safety precautions to reduce the risk of fire, electric shock
or personal injury. However, please note that these instructions and warnings are not substitutes for proper ac-
cident prevention measures.
3
