15
EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 61720-001 Screw 1
2 61720-002 Bushing 1
3 61720-004 Washer 1
4 61721-004 Bushing Washer 1
5 61721-005 Screw 1
6 61721-006 Washer 1
7 61721-007 Cylinder Cap 1
8 61721-008 Gasket 1
9 61720-010 Seal 1
10 61721-010 Spring 1
11 61720-015 Valve 1
12 61720-012 O-Ring 1
13 61720-013 O-Ring 1
14 61720-014 O-Ring 1
15 61720-016 Stop Washer 1
16 61720-018 Collar 1
17 61720-017 O-Ring 1
18 61721-018 Cylinder 1
19 61720-021 O-Ring 1
20 61721-020 O-Ring 1
21 61720-019 O-Ring 1
22 61721-022 Piston Assembly 1
23 61721-023 Bumper 1
24 61721-024 Body 1
25 61720-025 Seal 1
26 61721-026 Safe Guide 1
27 61720-031 Spring Pin 1
28 61721-028 Spring 1
29 61721-029 Safety Bracket A 1
30 61721-030 Safety Bracket B 1
31 61721-031 Bushing 1
32 61721-032 Washer 1
33 61720-061 Screw 1
34 61721-034 Rubber Cover 1
35 61720-032 O-Ring 1
36 61720-033 Trigger Valve Head 1
37 61720-034 Spring 1
38 61720-035 O-Ring 1
39 61721-039 Trigger Valve Stem 1
No. Part No. Description Qty.
40 61720-038 Trigger Valve Guide 1
41 61720-037 O-Ring 1
42 61721-042 Spring 1
43 61720-044 Washer 1
44 61721-044 Trigger Assembly 1
45 61720-042 Trigger Pin 1
46 61721-046 Latch Assembly 1
47 61721-047 Latch Cover 1
48 61721-048 Pin 1
49 61721-049 Plate 1
50 61721-050 Pin 1
51 61721-051 Rail 1
52 61720-046 Screw 1
53 61721-053 Front Plate 1
54 61721-054 Drive Guide 1
55 61721-055 Fixed Magazine 1
56 61721-056 Feeder Shoe 1
57 61721-057 Feeder Set 1
58 61720-059 Spring 1
59 61721-059 Movable Magazine 1
60 61721-060 Stop Plate 1
61 61720-068 Screw 1
62 61721-062 Screw 1
63 61721-063 Joint Guide 1
64 61721-064 Bushing 1
65 61721-065 Spring 1
66 61721-066 Lock 1
67 61721-067 Nut 1
68 61721-068 Washer 1
69 61721-069 Screw 1
70 61721-070 Screw 1
71 61721-071 Support 1
72 61721-072 Nut 1
73 61721-073 Soft Grip Sleeve 1
74 61720-070 O-Ring 1
75 61721-075 End Cap 1
76 61720-072 Air Plug 1
To Next Page
