Wen 61741K

13
EXPLODED VIEW AND PARTS LIST
No. Part No. Description Qty.
1 61741-001
Socket head cap screw,
M4x10
1
2 61741-002 Bushing 1
3 61741-003 Exhaust Cover 1
4 61741-004 Seal 1
5 61741-005
Socket head cap screw,
M5x22
4
6 61741-006 Washer 4
7 61741-007 Cylinder Cap 1
8 61741-008 Valve Seal 1
9 61741-009 Cylinder Cap Gasket 1
10 61741-010 Spring 1
11 61741-011 O-ring, Ø15.7x2 1
12 61741-012 O-ring, Ø38.8x3 1
13 61741-013 Valve 1
14 61741-014 O-ring, Ø33.5x3.5 1
15 61741-015 Stop Washer 1
16 61741-016 Collar 1
17 61741-017 O-ring, Ø50.5x2.5 1
18 61741-018 O-ring, Ø28.3x3 1
19 61741-019 Piston Assembly 1
20 61741-020 Cylinder 1
21 61741-021.1 O-ring, Ø36.3x2.5 1
22 61741-021.2 O-ring, Ø35.3x2.5 1
23 61741-022 Bumper 1
24 61741-023 Body 1
25 61741-024 Joint Guide 1
26 61741-026 Safety Guide 1
27 61741-027 Spring 1
28 61741-028 Safety Bracket A 1
29 61741-029 Safety Bracket Assembly 1
30 61741-030 No-Mar Tip 1
31 61741-040B.1 Rubber Washer 1
32 61741-041 Trigger 1
33 61741-040B.2 Trigger Pin 1
34 61741-038 Trigger Leaf Spring 1
35 61741-039 Pin 1
36 61741-025 Spring Pin 1
37 61741-031B.1 Trigger Valve Head Seal 1
38 61741-031B Trigger Valve Head 1
39 61741-032 Trigger Valve Spring 1
40 61741-033 O-ring, Ø5.5x1.5 2
41 61741-034 Trigger Valve Stem 1
42 61741-035 O-ring, Ø15x1.9 1
43 61741-036 Trigger Valve Guide 1
44 61741-037 Spring 1
45 61741-083 Lock Nut, M5 1
46 61741-081 Support 1
No. Part No. Description Qty.
47 61741-080
Socket head cap screw,
M4x8
2
48 61741-048
Socket head cap screw,
M5x18
1
49 61741-084 Grip 1
50 61741-085 End Cap Gasket 1
51 61741-086 End Cap 1
52 61741-087 Washer 3
53 61741-050
Socket head cap screw,
M4x16
5
54 61741-088 Air Plug, 1/4" NPT 1
55 61741-077 Rubber Cushion 1
56 61741-073 Magazine Cap 1
57 61741-039 Pin 1
58 61741-076 Reset Spring 1
59 61741-075 Magazine Lock 1
60 61741-074 Pin 1
61 61741-070 Screw, M4x6 2
62 61741-072 Rail 1
63 61741-069
Socket head cap screw,
M4x6
2
64 61741-068 Spring Washer 2
65 61741-067 Block 2
66 61741-071 Movable Magazine 1
67 61741-079 Pin 1
68 61741-078 Pin 1
69 61741-066 Magazine Spring 2
70 61741-065 Magazine Follower 1
71 61741-063 Fixed Magazine 1
72 61741-062 Pin 1
73 61741-061 Drive Guide 1
74 61741-060 Spacer 1
75 61741-059
Socket head cap screw,
M5x20
2
76 61741-053 Latch Sleeve 1
77 61741-055 Coil Spring Pin 1
78 61741-054 Latch Assembly 1
79 61741-056 Cover Plate A 1
80 61741-057 Guide Rail 1
81 61741-058 Coil Spring Pin 1
82 61741-064 Rail 1
83 61741-052B D-ring 1
84 61741B-084 Bushing 2
85 61741B-085 Shoe (Lower) 1
86 61741-047B Shoe Plate 1
87 61741B-087 Washer 1
88 61741B-088 Shoe (Upper) 1
89 61741B-09 Shoe Adjustment Knob 2
