Wen BG4260

EXPLODED VIEW & PARTS LIST
16
No. Part No. Description Qty.
1 4276-001 Bolt, M6x30 2
2 4276-002 Spring Washer, 6mm 2
3 4276-003 Flat Washer, 6mm 2
4 4276-004
Left Eye Shield
Bracket
1
5 4276-046
Left Eye Shield
Assembly
1
6 4276-006
Tool Rest Lock Knob
(M6)
2
7 4276-007 Left Work Rest 1
8 4276-008 Nut, M5 6
9 4276-009 Left Guard 1
10 4276-010 Carriage Bolt, M6x14 2
11 4276-011
Fastener Assembly,
M5x10
2
12 4276-012 Spark Deflector 2
13 4276-013
Fastener Assembly,
M5x10
4
14 4276-014 Flange 4
15 4276-015
Grinding Wheel ,
36-grit
1
16 4276-016 Hex Nut, M12-LH 1
17 4276-017
Left Wheel Guard
Cover
1
18 4276-018 Screw, M5x42 6
19 4276-019 Nut, M4 2
20 4276-020 End Bell 2
21 4276-021
Wavy Washer,
34.5mm
1
22 4276-022 Stator 1
23 4276-023 Power Cord Bushing 1
24 4276-024
Toothed Washer,
4mm
1
25 4276-025
Fastener Assembly,
M4x8
1
26 4276-026 Switch 1
27 4276-027 Switch Plate 1
No. Part No. Description Qty.
28 4276-028
Fastener Assembly,
M6x18
2
29 4276-029 Bottom Plate 1
30 4276-030
Fastener Assembly,
M4x6
2
31 4276-031 Rubber Feet 4
32 4276-032 Capacitor 1
33 4276-48
Eye Shield Locking
Knob
2
34 4276-034 Nut, M12-RH 1
35 4276-035
Right Wheel Guard
Cover
1
36 4276-036
Grinding Wheel,
60-grit
1
37 4276-037 Right Wheel Guard 1
38 4276-038 Right Work Rest 1
39 4276-039
Fastener Assembly,
M4x18
2
40 4276-040 Ball Bearing, 6202 2
41 4276-041 Cord Clamp 1
42 4276-042 Rotor 1
43 4276-043 Power Cord 1
44 4276-044
Right Eye Shield
Bracket
1
45 4276-045
Right Eye Shield
Assembly
1
46 BG4266-046 Base 1
