EXPLODED VIEW & PARTS LIST
No. Part Number Description Qty.
1 Screw, M5x16 4
2 Rubber Foot 4
3 Screw, M4x6 4
4 Base Plate 1
5 BG625V-005 Circuit Board 1
N.P. 4280-080
Fuse, T10AL250V
(5x20mm)
6 Self-tapping Screw, ST2.9x5 2
7 Circuit Board Cover 1
8 Coolant Tray 1
9 Speed Control Knob 1
10 Knob Bushing 1
11 Switch 1
12 Screw, M5x8 4
13 Switch Plate 1
14 BG625V-014 Potentiometer 1
15 Base 1
16 Nut, M4 13
17 Threaded Insert, 3/16" 1
18 Screw, M4x16 1
19 Bushing 3
20 Lock Washer, 4mm 1
21 Screw, M6x20 2
22 Screw, M4x7 2
23 BG625V-023 Capacitor, 300VAC 30uF 1
24 Screw, M4x145 4
25 Left End Bell 1
26 Wavy Washer, 35mm 1
27 Bearing, 6202-2RZ 2
28 Stator 1
29 4280-077 Wheel Dresser 1
30 Screw, M4x8 2
31 Wheel Dresser Mount 1
32 Light Subassembly 1
33 Power Cord 1
34 Cord Clip 1
35 Cord Plate 1
36 Rotor 1
No. Part Number Description Qty.
37 Right End Cover 1
38 Hex Bolt, M5x6 1
39 Flanged Hex Nut, M4 4
40 Speed Sensor Encoder 1
41 Right End Bell 1
42 Speed Sensor Optocoupler 1
43 Screw, M2.5x6 2
44 BG625V-044 Right Work Rest Bracket 1
45 Washer, 5mm 2
46 Spring Washer, 5mm 2
47 4280-078 Knob, M5 2
48 4280-070 Right Work Rest 1
49 BG625V-049 Right Work Rest Cover 1
50 Flat Washer, 6mm 4
51 4280-031 Bracket Knob, M6x44 2
52 Square-Neck Bolt, M5x51 2
53 Screw, M5x48 4
54 4276-035 Right Wheel Cover 1
55 4276-034 Nut, M12 1
56 4276-014 Wheel Flange 4
57 BG625V-057 Grinding Wheel, 80-grit 1
58 4276-013 Screw, M5x10 6
59 BG625V-059 Right Wheel Guard 1
60 Screw, M5x8 4
61 Bolt, M6x12 2
62 4280-036 Right Spark Deflector 1
63 4280-044 Eye Shield Mounting Bracket 2
64 4280-026 Eye Shield 2
65 Eye Shield Cover Plate 2
66 Screw, M4x12 4
67 4280-030 Knob, M6 2
68 4280-023 Left Spark Deflector 1
69 Left Wheel Guard 1
70 4276-015 Grinding Wheel, 36-grit 1
71 4276-016
Nut, M12
(Left-Hand Threaded)
1
72 4276-017 Left Wheel Cover 1
73 BG625V-073 Left Work Rest Bracket 1
74 4280-032 Left Work Rest 1
17
To Next Page
