Wen DT1315

EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
1 DT1315-001 Front Hub Cap 2
2 DT1315-002 Front Wheel Washer 2
3 DT1315-003 Front Axle Plate 2
4 DT1315-004 Front Axle 1
5 DT1315-005 Front Wheel 2
6 DT1315-006 Front Grill 1
7 DT1315-007 Air Filter #2 1
8 DT1315-008 Air Filter #1 1
9 DT1315-009 Air Filter #3 1
10 DT1315-010 Nut M8 2
11 DT1315-011 Press Plate 1
12 DT1315-012 Motor Fan Housing 1
13 DT1315-013 Top Housing Cover 1
14 DT1315-014 Top Handle 1
15 DT1315-015 Grass Flap Pin 1
16 DT1315-016 Grass Flap Spring 1
17 DT1315-017 Grass Flap 1
18 DT1315-018 Flap Spring Pin 1
19 DT1315-019 Fuse 1
20 DT1315-020 Counterbalance 1
21 DT1315-021 Base Housing 1
22 DT1315-022 Rear Wheel Axle Pin 2
23 DT1315-023 Screw 2
24 DT1315-024 Rear Wheel 2
26 DT1315-026 Rear Hub Cap 2
27 DT1315-027 Nut M6 1
28 DT1315-028 Nut M5 1
NO. PART NO. DESCRIPTION QTY.
29 DT1315-029 Blade Bearing Bracket 1
30 DT1315-030 Screw M5x25 1
31 DT1315-031 Hex Wrench 1
33 DT1315-033 Blade Bracket Arm 1
34 DT1315-034 Screw M6x30 1
35 DT1315-035 Right Depth Adjust Handle 1
36 DT1315-036 Left Depth Adjust Handle 1
37 DT1315-037 Handle Screw 15
38 DT1315-038 Front Wheel Pin 2
39 DT1315-039 Grass Bag Frame 1
40 DT1315-040 Grass Bag 1
41 DT1315-041 Housing Screw 21
42 DT1315-042 Bracket Screw 3
43 DT1315-043 Handle Frame Knob 4
44 DT1315-044 Handle Frame Bolt 4
46 DT1315-046 Middle Handle Frame 1
47 DT1315-047 Screw M6x45 4
48 DT1315-048 Power Cord Clip 1
49 DT1315-049 Hex Wrench Clip 1
50 DT1315-050 Lower Handle Bracket 2
51 DT1315-051 Lower Handle Rod 2
52 DT1315-052 Lower Bracket Screw 4
53 DT1315-053 Handle Height Adjust Knob 2
54 DT1315-054 Screw M8x50 2
58 DT1315-058 Depth Adjustment Plate 1
59 DT1315-059 Handle Bracket 1
NOTE: Not all parts may be available for purchase. Parts and accessories that wear
down over the course of normal use are not covered under the warranty.
BODY ASSEMBLY
19
