EXPLODED VIEW & PARTS LIST
18
NO. PART NO. DESCRIPTION QTY.
1 TC1014-001
Blade Subassembly
(Right)
1
2 TC1014-002 Hex Bolt, M8x40 2
3 TC1014-003
Blade Subassembly
(Right)
1
4 TC1014-004 Lock Nut, M8 2
5 TC1014-005
Hex Socket Flat-head Self-
Tapping Screw, ST6x25
4
6
Phillips Flat-head Self-
tapping Screw, ST4x16
6
7 Blade Guard 1
8 Connecting Shaft 1
9 Cover 1
10 Housing 1
11 Housing Cover 1
12 Cable Clamp 1
13 Sponge 1 1
14 TC1014-014 Knob 4
15 TC1014-015
Flanged Carriage Bolt,
M6x45
4
16 TC1014-016 Handle Frame 1
17 TC1014-017 Cord Clamp 2
18 TC1014-018 Lower Handle Frame 2
19 TC1014-019
Phillips Pan-head Self-
tapping Screw, ST4x16
10
20
Phillips Pan-head Self-
tapping Screw, ST4x18
2
100
TC1014-
100ASM
Gearbox Assembly 1
101 Gearbox Cover, Right 1
102 Sealing Ring Baffle 2
103 Sealing Ring 2
104 Oil Bearing 2
105 Washer 2
106 Worm Gear Shaft 1
107 Flat Key, 4x4x15mm 1
108 Worm Gear 1 1
109 Ball Bearing, 608Z 1
110 Worm Gear 2 1
111 Gearbox Baffle 1
NO. PART NO. DESCRIPTION QTY.
112 Gearbox Cover, Left 1
113 O-ring 1
114
Grease Port Screw,
M10x10
1
115
Screw with Washer,
M6x18
8
116 Sealing Ring 1
117 Splined Hub 1
118 Ball Bearing, 6001Z 1
200 Motor Assembly 1
20
Phillips Pan-head Self-
tapping Screw, ST4x18
4
117 Splined Hub 1
201 Lower Motor Housing 1
202 Sponge 2 1
203 Bearing, 6000Z 1
204 Rotor Assembly 1
109 Ball Bearing, 608Z 1
205 Wavy Washer, 22mm 1
206
Phillips Pan-head Self-
tapping Screw, ST4x65
2
207 Washer, 4mm 2
208 Stator Assembly 1
209 Inductor, 50 uH 2
210 TC1014-210 Thermal Breaker 1
211 Upper Motor Housing 1
212 TC1014-212 Capacitor, 0.22 uF 1
213 Carbon Brush Holder 2
214 TC1014-214 Carbon Brush 2
215
Phillips Pan-head Self-
tapping Screw, ST3x12
2
300
TC1014-
300ASM
Upper Handle Assembly 1
301 Right Handle Cover, Right 1
302 Trigger Spring 1
303 Trigger 1
304 Handle Button Spring 1
305 Switch Button 1
306 Right Handle Cover, Left 1
307 Rod 1
To Next Page
