Wen TC1014

EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
308 Handle Cover Plate 1
6
Phillips Flat-head Self-
tapping Screw, ST4x16
20
309
Phillips Pan-head Self-
tapping Screw, ST4x20
2
310 Left Handle Cover, Right 1
311 Left Handle Cover, Left 1
312 Power Cord 1
313 Power Cord Connector 1
314 Power Cord Sleeve 1
12 Cable Clamp 2
20
Phillips Pan-head Self-
tapping Screw, ST4x18
4
316 Switch 1
215
Phillips Pan-head Self-
tapping Screw, ST3x12
1
400
TC1014-
400ASM
Wheel & Axle Assembly 1
5 TC1014-005
Hex Socket Flat-head Self-
Tapping Screw, ST6x25
1
NO. PART NO. DESCRIPTION QTY.
402 Flat Washer, 5mm 2
403 TC1014-403 Wheel Cover 2
404 TC1014-404 R-clip 2
405 Flat Washer, 10mm 2
406 TC0714-080 Wheel 2
407 Wheel Bracket Assembly 1
408
Phillips Countersunk Self-
tapping Screw, ST4x16
4
409 Wheel Adjustment Shaft 1
410 Wheel Adjustment Spring 1
411 Wheel Adjustment Knob 1
412 Release Ring 1
413 Wheel Adjustment Bracket 1
115
Screw with Washer,
M6x18
3
19
NOTE: Not all parts may be available for purchase. Parts and accessories that wear
down over the course of normal use are not covered under the warranty.
