Wen TC1318

EXPLODED VIEW & PARTS LIST
18
NO. PART NO. DESCRIPTION QTY.
1 TC1318-001
Blade Subassembly
(Right)
1
2 TC1014-002 Hex Bolt, M8x40 2
3 TC1318-003
Blade Subassembly
(Right)
1
4 TC1014-004 Lock Nut, M8 2
5
Hex Socket Flat-head Self-
Tapping Screw, ST6x25
4
6
Phillips Flat-head Self-
tapping Screw, ST4x16
15
7 Blade Guard 1
8 Connecting Shaft 1
9 Cover 1
10 Housing 1
11 Housing Cover 1
12 Cable Clamp 1
13 Sponge 1 1
14 TC1014-014 Knob 4
15 TC1014-015
Flanged Carriage Bolt,
M6x45
4
16 TC1318-016 Handle Frame 1
17 TC1014-017 Cord Clamp 2
18 TC1318-018 Frame Plug 2
19 TC1318-019 Lower Handle Frame 2
20 TC1318-020 Lock Nut, M6 6
21 TC1318-021 Wavy Washer, 6mm 6
22 TC1318-022 Carriage Bolt, M6x32 4
23 TC1318-023
Lower Handle Frame with
Bracket
1
100
TC1318-
100ASM
Gearbox Assembly 1
101 Gearbox Cover, Right 1
102 Sealing Ring Baffle 2
103 Sealing Ring 2
104 Oil Bearing 2
105 Washer 2
106 Worm Gear Shaft 1
107 Flat Key, 4x4x15mm 1
108 Worm Gear 1 1
NO. PART NO. DESCRIPTION QTY.
109 Ball Bearing, 608Z 1
110 Worm Gear 2 1
111 Gearbox Baffle 1
112 Gearbox Cover, Left 1
113 O-ring 1
114
Grease Port Screw,
M10x20
1
115
Screw with Washer,
M6x18
8
116 Sealing Ring 1
117 Splined Hub 1
118 Ball Bearing, 16100Z 1
119 Ball Bearing, 6000Z 1
200 Motor Assembly 1
6
Phillips Flat-head Self-
tapping Screw, ST4x16
4
117 Splined Hub 1
201 Lower Motor Housing 1
202 Sponge 2 1
119 Ball Bearing, 6000Z 1
203 Rotor Assembly 1
109 Ball Bearing, 608Z 1
204 Wavy Washer, 22mm 1
205
Phillips Pan-head Self-
tapping Screw, ST4x70
2
206 Washer, 4mm 2
207 Stator Assembly 1
208 Inductor, 50 uH 2
209 TC1318-209 Thermal Breaker 1
210 Upper Motor Housing 1
211 TC1014-212 Capacitor, 0.22 uF 1
212 Carbon Brush Holder 2
213 TC1014-214 Carbon Brush 2
214
Phillips Pan-head Self-
tapping Screw, ST3x12
2
300
TC1318-
300ASM
Upper Handle Assembly 1
301 Right Handle Cover, Right 1
302 Trigger Spring 1
303 Trigger 1
